Screws
Have a look at the charts below to choose the correct sized Screw.
Screw Diamaters
| Size No. | Size mm | Wood Screws Slotted Drive | Chipboard Screws Pozi Drive | Chipboard Screws Square Drive | Self Tapping Screws Phillips Drive | Drywall Screws Phillips Drive |
|---|---|---|---|---|---|---|
| 0 | 1.5 | PZ0 | PH0 | |||
| 1 | 1.9 | PZ0 | PH0 | |||
| 2 | 2.2 | 3mm | PZ1 | PH1 | ||
| 3 | 2.5 | PZ1 | PH1 | |||
| 4 | 2.8 | 5mm | PZ1 | #0 | PH1 | |
| 5 | 3.2 | 5mm | PZ2 | #1 | PH2 | |
| 6 | 3.5 | 6mm | PZ2 | #1 | PH2 | PH2 |
| 7 | 3.8 | 6mm | PZ2 | #1 | PH2 | |
| 8 | 4.2 | 6mm | PZ2 | #2 | PH2 | PH2 |
| 9 | 4.5 | 8mm | PZ2 | #2 | PH2 | |
| 10 | 4.8 | 8mm | PZ3 | #2 | PH2 | |
| 11 | 5.2 | PZ3 | #3 | PH3 | ||
| 12 | 5.5 | 8mm | PZ3 | #3 | PH3 |
